Fuel cell modules
Ready-to-connect fuel cell modules for flexible power classes
VINUITY® fuel cell modules are based on our proprietary stack platforms and cover a wide power range from 5 to 250 kilowatts. Each module is equipped with all essential components required for system integration, including air supply, DC/DC converters, and thermal management. For operation, only three external connections are required: air, hydrogen, and cooling.
The modules can be deployed individually or combined in multi-module configurations, creating scalable system solutions for mobile and stationary applications with varying power demands.
With the aim of reducing technical complexity, simplifying integration processes, and sustainably increasing operational reliability, VINUITY® continuously advances the development of its modules.
Features
- Power range from 5 kW to 250 kW
- Operating temperature from -30 °C to 55 °C
- Service life up to 30,000 hours
- Compact system and high system efficiency
- Protected according to IP67 and SAEJ2380
- Supplied with (integrated) air compressor and DCDC*
- Highly efficient hydrogen recirculation and advanced humidification
Fuel cell modules at a glance
The VINUITY fuel cell modules in the VISTAH series cover a wide range of outputs: from compact 30 kW units to powerful 250 kW units. All variants are based on a common system architecture and can be flexibly integrated into mobile and stationary applications. The following overview compares the key technical specifications.
VISTAH 30
VISTAH 60
VISTAH 80
VISTAH 110
VISTAH 130
VISTAH 200
Our standard systems and their properties are summarized in the following table.
| VISTAH 30 | VISTAH 60 | VISTAH 80 | VISTAH 110 | VISTAH 130 | VISTAH 200 | |
|---|---|---|---|---|---|---|
| Rated power (kW) | 30 | 60 | 80 | 110 | 130 | 200 |
| Peak power (kW) | 35 | 62 | 83 | 115 | 135 | 250 |
| Idle power (kW) | 3 | 5 | 6 | 9 | 10 | 15 |
| Stack operation voltage (V) | 80 - 125 | 110 - 220 | 170 - 290 | 260 - 460 | 280 - 380 | 360 - 560 |
| System efficiency (%) | 42 - 57 | 42 - 58 | 45 - 60 | 45 - 60 | 45 - 60 | 45 - 60 |
| Working altitude (m) | < 3000 | < 3000 | < 3000 | < 3000 | < 3000 | < 3000 |
| Lifetime (h) | < 30000 | < 30000 | < 30000 | < 30000 | < 30000 | < 30000 |
| Weight (kg) | 150 | 165 | 185 | 225 | 210 | 280 |
| Dimensions (mm) | 911 x 511 x 657 | 980 x 560 x 700 | 938 x 714 x 717 | 1100 x 671 x 677 | 1120 x 717 x 695 | 1094 x 746 x 988 |
| Air compressor integrated* | ✓ | ✓ | ✓ | ✓ | ||
| DCDC integrated** | ✓ | ✓ | ✓ |
* Customization to specific requirements is possible.
** All systems are supplied with an air compressor and DC/DC converter. If these components are listed as non-integrated, they are delivered separately from the module (outside the specified installation envelope).
All specifications and data are subject to change without notice as an integral part of continuous improvements to design, function, reliability and customer satisfaction.
Download fuel cell module overview
Application scenarios
Our modules are used wherever an emission-free, grid-independent, and scalable energy supply is required. They can be flexibly integrated into mobile applications such as buses, trucks, and forklifts, or operated as a stationary solution in a network, for example in data centers or industrial energy infrastructures.
Data centers
Emergency power supply for data centers is an increasing challenge, especially in urban areas, due to increasingly stringent regulations regarding gaseous, particle and noise emissions.
